Solenoid operated spool valve
Solenoid operated spool valve Solenoid operated spool valve

TYPE CODE PERFORMANCE SPECIFICATIONS
2
WD M F A06 - - / - K9 # Oil viscosity u = 30 mm /s
Spool valve, direct operated p = f (Q) Performance limits Q = f (Q) Leakage volume flow characteristics
Measured with nominal voltage -10% L P → T
Slip-on coil, Medium
at 50 °C (steady-state temperature) Q [cm /min]
3
Flange construction L K4199
300
International standard interface ISO, NG6 p [bar] AB1 / AB2 ADB ACB AB3/BEA 250
350 K4196 200 BEA
Designation of symbols acc. to table 300 150
250 100 AB1 / AB2
AB3
Nominal voltage U 12 VDC G12 115 VAC R115 200 50 ACB / ADB
N
24 VDC G24 230 VAC R230 150 0
without coil X5 100 0 50 100 150 200 250 300 350 p [bar]
50
Slip-on coil Metal housing, round W 0 Q [l/min]
Metal housing, square M 0 10 20 30 40 50

Connection execution Connector socket EN 175301-803 / ISO 4400 D Δp = f (Q) Pressure drop volume flow characteristic Volume flow direction
Connector socket AMP Junior-Timer J (only for U ≤ 75 VDC) per control edge
N
Connector Deutsch DT04 - 2P G (only for U ≤ 75 VDC) Symbol P-A P-B P-T A-T B-T
N
p [bar] AB1 / AB3 2 2 - 3 3
Sealing material NBR 20 K4291 ACB 1 1 - 2 2
FKM (Viton) D1 18 4 3
NBR 872 y-Z604 16 ADB 1 1 - 1 1
14 2
12 1 BEA 1 1 4 2 2
Stainless 10
8
6
Design index (subject to change) 4 Attention! For valves for the temperature ranges „-40 °C to…”
2
1.2-59S 0 (Z604) the leakage volume flow can be up to eight times
0 5 10 15 20 25 30 35 40 45 50 Q [l/min] higher.

ELECTRICAL SPECIFICATIONS HYDRAULIC SPECIFICATIONS ACCESSORIES STANDARDS
Protection class Connection execution D: IP65 Working pressure p = 350 bar Mating connector grey (A) Article no. 219.2001 Mounting interface ISO 4401-03
max
Connection execution J: IP66 Tank pressure p T max = 200 bar Mating connector black (B) Article no. 219.2002 Solenoids DIN VDE 0580
Connection execution G: IP67 and IP69K Maximum volume flow Q = 50 l/min, see characteristics Mounting screws Data sheet 1.0-60 Connection execution D EN 175301 – 803
max
Relative duty factor 100 % DF Leakage oil See characteristics Threaded subplates Data sheet 2.9-30 Protection class EN 60 529
Switching frequency 15'000 / h Fluid Mineral oil, other fluid on request Multi-station subplates Data sheet 2.9-60 Contamination efficiency ISO 4406
Service life time 10 (number of switching cycles, Viscosity range 12 mm /s…320 mm /s Horizontal mounting blocks Data sheet 2.9-100
7
2
2
theoretically) Temperature range -25…+70 °C (NBR)
Voltage tolerance ± 10 % with regard to nominal voltage fluid -20…+70 °C (FKM) Technical explanations Data sheet 1.0-100
Standard nominal 12 VDC, 24VDC, 115 VAC, 230 VAC Contamination Class 20 / 18 / 14 Filtration Data sheet 1.0-50 SEALING MATERIAL
voltage AC = 50 to 60 Hz, rectifier integrated in efficiency Relative duty factor Data sheet 1.1-430 NBR or FKM (Viton) as standard, choice in the type code
the connector socket Filtration Required filtration grade ß 10…16 ≥ 75,
Note! Other electrical specifications see data sheet 1.1-182 see data sheet 1.0-50 INSTALLATION NOTES SURFACE TREATMENT
(slip-on coil W) and 1.1-181 (slip-on coil M) The valve body, the cover and the socket head screws are made
Mounting type Flange mounting ◆
4 fixing holes for of stainless steel
socket head screws M5 x 50 ◆ The slip-on coil and the armature tube are zinc nickel coated
Mounting position Any, preferably horizontal
Tightening torque Fixing screws M = 5,1 Nm (screw
D
quality A4)
M = 9 Nm knurled nut
D
Note! The length of the fixing screw depends on the base
material of the connection element.

Attention! For stack assembly please observe the remarks in the
operating instructions

www.wandfluh.com Illustrations are not binding Data subject to change 2/4 Edition: 22 48 1.2-59S E www.wandfluh.com Illustrations are not binding Data subject to change 3/4 Edition: 22 48 1.2-59S E
