Back pressure valve
                                                                                         Back pressure valve                                                                                                           Back pressure valve


       GENERAL SPECIFICATIONS                              HYDRAULIC SPECIFICATIONS                                                DIMENSIONS
       Designation        Back pressure valve               Working pressure   p  = 400 bar                                        Sandwich execution                                   Sandwich execution
                                                                                max
       Construction       Direct or pilot operated          Nominal pressure   P  N max                                            G.DSA10-A / B                                        G.DSA10-T
       Mounting           Sandwich construction             range              A: 63, 210, 315 bar                                                   P                                                      P
       Nominal size       NG10 according to ISO 4401-05                        V: 63, 160, 350 bar                                                A      B     60                                        A      B      60
       Actuation          Manually                          Minimum pressure   See characteristics                                              T          To               38                         T          To               21.5
       Ambient temperature  -25…+70 °C                      Maximum volume flow  Q  = 100 l/min                                        MD= 60Nm  10                 18                      MD= 60Nm  10                    32
                                                                                max
       Weight             2,3 kg                            Fluid              Mineral oil, other fluid on request                               66                   49.5                             80                    49.5
                                                            Viscosity range    12 mm /s…320 mm /s                                       53 max.    163 max.    110                          53 max.    178 max.    125
                                                                                            2
                                                                                   2
                                                            Temperature range   -25…+70 °C (NBR)                                   G.DSA10-A: Cartridge on A side
                                                            fluid              -20…+70 °C (FKM)                                    G.DSA10-B: Cartridge on B side
                                                            Contamination      Class 18 / 16 / 13
                                                            efficiency                                                             Type of adjustment       Type of adjustment
                                                            Filtration         Required filtration grade ß 6…10 ≥ 75,              G.SSA10                  G.ASA10
                                                                               see data sheet 1.0-50
                                                           Note!    Other specifications, see data sheet of the screw-in
                                                                    cartridges
                                                                                                                                       MD= 60Nm                 MD= 60Nm
                                                                                                                                       46 max.                  53 max.

       ACTUATION                                           STANDARDS
       Actuation          S = lockable key adjustment       Mounting interface  ISO 4401-05
                          D = lockable knob adjustment      Contamination      ISO 4406                                            HYDRAULIC CONNECTION                                 PARTS LIST
                                                            efficiency
       Note!   Other specifications, see data sheet of the screw-in                                                                                                                      Position Article  Description
               cartridges                                                                                                                                  54                                 10 160.2140  O-ring ID 14,00 x 1,78 (NBR)
                                                                                                                                                          P                                      160.6141  O-ring ID 14,00 x 1,78 (FKM)


                                                                                                                                                                        1.5
                                                                                                                                                      A        B           16.8
                                                                                                                                                46
                                                                                                                                                                           9.7
       SEALING MATERIAL                                    SURFACE TREATMENT                                                                        T            To
       NBR or FKM (Viton) as standard, choice in the type code  ◆  The sandwich bodies made of steel are zinc-phosphated
                                                                                                                                                           20.8
                                                                                                                                                         24
       PERFORMANCE SPECIFICATIONS

       Δp = f (Q)  Pressure volume flow characteristic     Note!    Detailed performance limites and additional hydraulic          ACCESSORIES                                          INSTALLATION NOTES
                  over the non-return valve                         specifications may by drawn from the data sheets of the         Types of adjustment for screw-in   Data sheet 2.0-50  Mounting type     Sandwich mounting
          p [bar]                                                   corresponding installed pressure relief cartridge.              cartridges                                                              4 fixing holes for
         4  K0319                                                                                                                   Threaded subplates               Data sheet 2.9-40                      socket head screws or studs M6
         3                                                 Attention!  The performance data especially the „pressu-                 Multi-station subplates          Data sheet 2.9-70   Mounting position  Any, preferably horizontal
                                                                    re-flowcharacteristic„ on the data sheets of the                Module type manifold blocks      Data sheet 2.9-110  Tightening torque  Fixing screws M  = 8,9 Nm (quality 8.8,
                                                                                                                                                                                                                       D
         2                                                          screw-in catridges refere to the screw-in cartridges                                                                                    zinc coated)
         1                                                          only. The additional pressure drop of the sandwich body         Technical explanations           Data sheet 1.0-100                     Screw-in cartridge M  = 60 Nm
                                                                                                                                                                                                                           D
                                                                    must be taken into consideration.                               Filtration                       Data sheet 1.0-50
         0
           0     20     40     60     80    100 Q [l/min]



       VALVES INSTALLED
       The following screw-in cartridges are used in the sandwich body.

       Article       Description                                                       Data sheet no.
       BV.PM22       Pressure relief cartridge pilot operated                          2.1-530
       BA.PM22       Pressure relief cartridge direct operated                         2.1-540
