Back pressure valve
Back pressure valve

DIMENSIONS
Sandwich execution Sandwich execution
G.DSA06- A / B / AB G.DSA06-T
T T
17.5
A B A B
45 45
17.5
P P
10 MD= 60Nm
20 10 30 15.5 17.5 68
MD= 18Nm 39.5 39.5 104
MD=60Nm
70
140 5
G.DSA06-A: Cartridge on A side
G.DSA06-B: Cartridge on B side
G.DSA06-AB: Cartridge on A and B side
Type of adjustment Type of adjustment
G.SSA06 G.ASA06

MD= 50Nm MD=50Nm
46 max. 53 max.

HYDRAULIC CONNECTION PARTS LIST
Position Article Description
17.8
10 160.2093 O-ring ID 9,25 x 1,78 (NBR)
T 160.6092 O-ring ID 9,25 x 1,78 (FKM)
A B 20 160.2111 O-ring ID 11,11 x 1,78 (NBR)
31 21 32.5 160.6111 O-ring ID 11,11 x 1,78 (FKM)

P 30 238.5404 Screw plug VSTI M22 x 1,5
21.5
40.5

ACCESSORIES INSTALLATION NOTES
Types of adjustment for screw-in Data sheet 2.0-50 Mounting type Sandwich mounting
cartridges 4 fixing holes for
Threaded subplates Data sheet 2.9-30 socket head screws or studs M5
Multi-station subplates Data sheet 2.9-60 Mounting position Any, preferably horizontal
Tightening torque Fixing screws M = 5,2 Nm (quality 8.8,
Module type manifold blocks Data sheet 2.9-100 D
zinc coated)
Technical explanations Data sheet 1.0-100 Screw-in cartridge M = 60 Nm
Filtration Data sheet 1.0-50 D

Wandfluh AG Postfach CH-3714 Frutigen
Tel. +41 33 672 72 72 Fax +41 33 672 72 12 sales@wandfluh.com

www.wandfluh.com Illustrations are not binding Data subject to change 3/3 Edition: 21 32 2.1-740 E
