Solenoid operated spool valve
Solenoid operated spool valve Solenoid operated spool valve

DIMENSIONS MANUAL OVERRIDE STANDARDS
4/3-way valve (spring centred) 4/2-way valve (spring reset) ◆ Integrated (–) Actuation pin integrated in the armature tube. Mounting interface ISO 4401-05
4/2-way valve (impulse) Actuation by pressing the pin Solenoids DIN VDE 0580
◆ Push-button (HF1) Integrated in the knurled nut. Actuation by
A B A MD= 10.5Nm (8.8) Connection execution D EN 175301 – 803
13.5Nm (10.9)
pressing the push-button
◆ Spindle (HS1) Integrated in the knurled nut. Actuation by turning Protection class EN 60 529
104 64 the spindle (continuously variable valve actuation) Contamination efficiency ISO 4406
W = 69.5 Attention! The actuation of the manual override is possible up to a
29 tank pressure of:
20 bar Integrated (–)
10 70 60 10 50 6.5 20 bar Push-button (HF1)
307 MD= 5Nm 10.5 80 bar Spindle (HS1)
35 72 93.2 14.2
HF1 HS1 214.4
64.9 71.4
51.4 51.4 30
80 90 A ACCESSORIES INSTALLATION NOTES

105.3 60 Mating connector grey (A) Article no. 219.2001 Mounting type Flange mounting
4 fixing holes for
M= 75.5 Mating connector black (B) Article no. 219.2002 socket head screws M6 x 40
Fixing screws Data sheet 1.0-60
Mounting position Any, preferably horizontal
Threaded subplates Data sheet 2.9-40
10 68 Tightening torque Fixing screw
Multi-station subplates Data sheet 2.9-70
35 72 M = 10,5 Nm ± 10 % (screw quality 8.8,
D
214.4 Horizontal mounting blocks Data sheet 2.9-110 zinc coated)
Technical explanations Data sheet 1.0-100 max. tank pressure 80 bar
Filtration Data sheet 1.0-50 M = 13,5 Nm ± 10 % (screw quality 10.9,
D
Relative duty factor Data sheet 1.1-430 zinc coated)
Knurled nut M = 5 Nm
D
HYDRAULIC CONNECTION PARTS LIST Note! The length of the fixing screw depends on the base
Position Article Description material of the connection element.
54
10 206.3… W.E64 / 31 x 72
P 260.9… M.S60 / 31 x 72

1.5 50 160.2120 O-ring ID 12,42 x 1,78 (NBR)
A B 16.8
46 160.8124 O-ring ID 12,42 x 1,78 (FKM)
9.7
T To 60 160.2282 O-ring ID 28.24 x 2.62 (NBR)
70 154.2706 Knurled nut
20.8
80 253.7006 HF1-M24
24
90 253.7005 HS1-M24

SEALING MATERIAL SURFACE TREATMENT
NBR or FKM (Viton) as standard, choice in the type code Standard:
-The valve body is painted with a two component paint
-The armature tube, the slip-on coil and the plug screw are zinc-ni-
ckel coated

Optionally (K8):
-All external parts are zinc-nickel coated
ISO 9227 (800 h) salt spray test

Wandfluh AG Postfach CH-3714 Frutigen
Tel. +41 33 672 72 72 Fax +41 33 672 72 12 sales@wandfluh.com

www.wandfluh.com Illustrations are not binding Data subject to change 4/5 Edition: 21 22 1.2-76 E www.wandfluh.com Illustrations are not binding Data subject to change 5/5 Edition: 21 22 1.2-76 E
