Spool valve
                                                                                                  Spool valve                                                                                                                 Spool valve


       TYPE CODE                                                                                                                   PERFORMANCE SPECIFICATIONS
                                                                                                                                                    2
                                                                                     WD  L  F  A03  -     -     #                  Oil viscosity u = 30 mm /s
       Spool valve, direct operated
                                                                                                                                    p = f (Q)  Performance limits                        Q  = f (Q)  Leakage volume flow characteristics
                                                                                                                                                                                          L
       Pneumatically operated                                                                                                                                                                       per control edge
                                                                                                                                        p [bar]                                            Q [cm /min]
                                                                                                                                                                                                3
       Flange construction                                                                                                                                                   ACB/AC1/CB2
                                                                                                                                     350  K0655                              ADB/AD1/DB2  40  K4262
       Mounting interface acc. to Wandfluh standard, NG3-Mini                                                                        300
                                                                                                                                     250                                                  30
                                                                                                                                     200
       Designation of symbols acc. to table                                                                                                                 AB1/AB2
                                                                                                                                     150                                                  20
       Sealing material                NBR                                                                                           100                                                  10
                                       FKM (Viton)        D1                                                                          50             AB3
                                                                                                                                       0
                                                                                                                                         0   1   2    3   4   5   6    7   8  Q [l/min]    0                                      p [bar]
       Design index (subject to change)                                                                                                                                                      0   50   100  150  200  250   300  350
       1.6-15
                                                                                                                                    Δp = f (Q)  Pressure drop-volume flow characteristics                       Volume flow direction
       HYDRAULIC SPECIFICATIONS                            SURFACE TREATMENT                                                           p [bar]                                           Symbol         P - A  P - B  P - T  A - T  B - T
       Working pressure   p   = 350 bar (p  < 20 bar)       ◆  The valve body is painted with a two component paint                   16  K4261                                          AB1 / AB2 / AB3  3     3       -      2      2
                                      T
                           max
                          p   = 315 bar (p  > 20 bar)       ◆  The cover is zinc-nickel coated                                        12                                    3            ACB / AC1/ CB2  3      3       -      1      1
                           max        T                       The pneumatic actuation is zinc coated
       Tank pressure      p    = 100 bar                    ◆                                                                                                                            ADB / AD1 / DB2  2     2       -      1      1
                           T max                                                                                                       8                                    2
       Maximum volume flow  Q  = 8 l/min, see characteristics                                                                                                               1
                           max
                                                                                                                                       4
       Leakage oil        See characteristics                                                                                          0
       Fluid              Mineral oil, other fluid on request                                                                           0    1   2   3   4    5   6   7   8   Q [l/min]
       Viscosity range    12 mm /s…320 mm /s
                               2
                                        2
       Temperature range   -25…+70 °C (NBR)
       fluid              -20…+70 °C (FKM)                 MANUAL OVERRIDE                                                         DIMENSIONS
       Contamination      Class 20 / 18 / 14               None                                                                    4/3-way valve (spring centred)                       4/2-way valve (spring reset)
       efficiency                                                                                                                  4/2-way valve (impulse)
       Filtration         Required filtration grade ß 10…16 ≥ 75,                                                                                                                                            7.5
                          see data sheet 1.0-50
                                                                                                                                                                                                             4.2    MD= 2.6Nm
                                                                                                                                                                                                                      5

                                                                                                                                                                                          29                                    29
      SEALING MATERIAL                                     STANDARDS                                                                                                                          G1/8"                   25            30
      NBR or FKM (Viton) as standard, choice in the type code
                                                            Mounting interface  Wandfluh standard
                                                            Contamination      ISO 4406                                                 10                                                  40     10         50            20  30
                                                            efficiency                                                                                                                  MD=1.2Nm      35          38      7      MD= 1.2Nm
                                                                                                                                                      114                                                    83


       INSTALLATION NOTES                                  ACCESSORIES
                                                                                                                                   HYDRAULIC CONNECTION                                 PARTS LIST
       Mounting type      Flange mounting                   Fixing screws                Data sheet 1.0-60
                          3 fixing holes for                Threaded subplates           Data sheet 2.9-05                                                                               Position Article  Description
                          socket head screws M4 x 30        Multi-station subplates      Data sheet 2.9-45                                                P                                   10 254.1000  Pneumatic actuation CKIII
       Mounting position  Any, preferably horizontal        Horizontal mounting blocks   Data sheet 2.9-85                                            A      B   11  21                       20 056.4200  Cover
       Tightening torque  M  = 2,6 Nm (screw quality 8.8,   Technical explanations       Data sheet 1.0-100                                         T         T 0                             30 246.0109  Socket head screw M3 x 8 DIN 912
                            D
                          zinc-coated) Fixing screws                                                                                                                                          40 246.0141  Socket head screw M3 x 40 DIN 912
       Note!   The length of the fixing screw depends on the base   Filtration           Data sheet 1.0-50                                               10
               material of the connection element.                                                                                                                                            50 160.2045  O-ring ID 4,50 x 1,50 (NBR)
                                                                                                                                                         20

                                                                                                                                                                                        Wandfluh AG  Postfach  CH-3714 Frutigen
                                                                                                                                                                                        Tel. +41 33 672 72 72  Fax +41 33 672 72 12  sales@wandfluh.com

                           www.wandfluh.com  Illustrations are not binding  Data subject to change  2/3  Edition: 21 33  1.6-15 E                      www.wandfluh.com  Illustrations are not binding  Data subject to change  3/3  Edition: 21 33  1.6-15 E
