Proportional pressure relief valve
                                                                             Proportional pressure relief valve                                                                                           Proportional pressure relief valve


       GENERAL SPECIFICATIONS                              HYDRAULIC SPECIFICATIONS                                                DIMENSIONS                                           HYDRAULIC CONNECTION
       Designation        Proportional pressure relief valve  Working pressure  p  = 400 bar                                                                                            Cavity drawing according to ISO 7789–42–02–0–07
                                                                                max
       Construction       Pilot operated                    Tank pressure      p   = p  + 15 bar
                                                                                T max  P                                                                             s41
       Mounting           Screw-in cartridge construction   Nominal pressure   P  = 100 bar, 200 bar, 275 bar, 350 bar                                                                                          M42x2
                                                                                N
       Nominal size       M42 x 2 according to ISO 7789     range                                                                         15                          M42x2
       Actuation          Proportional solenoid             Volume flow range  Q = 5…400 l/min                                        81.7   MD=5.5Nm                       (2)
       Ambient temperature  -25…+70 °C                      Leakage oil        See characteristics                                     37.1                                       (1)                                  (2)
       Weight             0,90 kg                           Hysteresis         ≤ 5 % at optimal dither signal
       MTTFd              150 years                         Repeatability      ≤ 2 % at optimal dither signal                           W =
                                                            Fluid              Mineral oil, other fluid on request
                                                            Viscosity range    12 mm /s…320 mm /s                                         12   17      10   18       50     70    60                               (1)
                                                                                            2
                                                                                   2
                                                                                                                                       MD=5Nm
                                                            Temperature range   -25…+70 °C (NBR)                                                         85.8             56.7
       ELECTRICAL SPECIFICATIONS                            fluid              -20…+70 °C (FKM)                                                               148.7                     Note!    For detailed cavity drawing and cavity tools see data
                                                            Contamination      Class 18 / 16 / 13                                                                                                sheet 2.13-1048
       Protection class   Connection execution D: IP65                                                                                                                     HB0
                                                                                                                                                                          15
                          Connection execution J: IP66      efficiency                                                                                                MD= 9.5Nm
                          Connection execution G: IP67 and IP69K  Filtration   Required filtration grade ß 6…10 ≥ 75,
       Relative duty factor  100 % DF                                          see data sheet 1.0-50
       Standard nominal   12 VDC, 24 VDC                                                                                               80.8   35
       voltage
       Limiting current at  I  = 1320 mA (U  = 12VDC)                                                                                      M =
                                     N
                           G
       50 °C              I  = 660 mA (U  = 24VDC)
                           G        N
                                                                                                                                                       10
       Note!   Other electrical specifications see data sheet 1.1-173
               (slip-on coil W) and 1.1-174 (slip-on coil M)
                                                                                                                                   PARTS LIST                                           ACCESSORIES
                                                                                                                                     Position Article  Description                       Proportional amplifier      Register 1.13
       PERFORMANCE SPECIFICATIONS                                                                                                        10 206.2…  W.S37 / 19 x 50                      Electric plug B (black)     Article no. 219.2002
                       2
       Oil viscosity u = 30 mm /s                                                                                                           260.5…  M.S35 / 19 x 50                      Threaded body               Data sheet 2.9-200
       p  = f (Q)  Pressure volume flow characteristics     p  = f (Q)  Pressure volume flow characteristics                             12 154.2700  Knurled nut                        Technical explanations      Data sheet 1.0-100
        red                                                  red
                  Maximal adjustable pressure                         Minimal adjustable pressure                                        15 253.8000  HB4,5 manual override              Hydraulic fluids            Data sheet 1.0-50
           p [bar]                                             p [bar]                                                                      239.2033  HB0 Screw plug                     Filtration                  Data sheet 1.0-50
                                   P N = 350 bar
         400  K0731_2                                         30  K0732_2                                                                17 160.2187  O-ring ID 18,72 x 2,62 (NBR)
                                                              25                                   P N = 350 bar
         300                                   P N = 275 bar                                       P N = 275 bar                         18 160.2170  O-ring ID 17,17 x 1,78 (NBR)
                                                              20                                   P N = 200 bar
                                                                                                   P N = 100 bar
         200                                   P N = 200 bar  15                                                                         50 160.2377  O-ring ID 37,77 x 2,62 (NBR)      MANUAL OVERRIDE
                                                                                                                                            160.6379
                                                                                                                                                    O-ring ID 37,77 x 2,62 (FKM)
         100                                   P N = 100 bar  10                                                                                                                        HB4,5
                                                               5                                                                         60 160.2314  O-ring ID 31,42 x 2,62 (NBR)
           0                                                   0                                                                            160.6315  O-ring ID 31,42 x 2,62 (FKM)      Optionally: Screw plug (HB0), no actuation possible
            0   50  100 150  200 250 300 350 400  Q [l/min]     0   50  100 150  200 250 300 350 400  Q [l/min]
                                                                                                                                         70 049.8364  Backup ring PTSM rd 29,1 x 33,6 x 1 ,4

       p  = f (n)  Pressure adjustment characteristics      Q  = f (p)  Leakage volume flow characteristic                         SURFACE TREATMENT                                    SEALING MATERIAL
        red
                                                             L
                  Measured at Q = 30 l/min
                                                                                                                                    ◆  The cartridge body, the slip-on coil and the armature tube are   NBR or FKM (Viton) as standard, choice in the type code
           p [bar]                                             Q  [cm /min]                                                           zinc-nickel coated
                                                                    3
                                                                L
         400  K0733_2                                        2000  K0734_2
                                               P N = 350 bar
                                                                                                                                   STANDARDS                                            INSTALLATION NOTES
         300                                   P N = 275 bar  1500
         200                                   P N = 200 bar  1000                                                                  Cartridge cavity      ISO 7789                       Mounting type      Screw-in cartridge M42 x 2
                                                                                                                                    Solenoids             DIN VDE 0580                   Mounting position  Any, preferably horizontal
         100                                   P N = 100 bar  500                                                                   Connection execution D  EN 175301 – 803              Tightening torque  M  = 100 Nm Screw-in cartridge
                                                                                                                                                                                                             D
           0                                                   0                                                                    Protection class      EN 60 529                                         M  = 5 Nm knurled nut
                                                                                                                                                                                                             D
            0   10  20  30  40 50 60 70 80 90  100 l [%]         0   50   100  150  200  250  300  350 p [bar]                      Contamination efficiency  ISO 4406                                      M  = 9,5 Nm HB0
                                                                                                                                                                                                             D
                                                                                                                                                                                                            M  = 5,5 Nm HB4,5
                                                                                                                                                                                                             D
                                                                                                                                                                                        Wandfluh AG  Postfach  CH-3714 Frutigen
                                                                                                                                                                                        Tel. +41 33 672 72 72  Fax +41 33 672 72 12  sales@wandfluh.com
                         www.wandfluh.com  Illustrations are not binding  Data subject to change  2/3  Edition: 17 45  2.3-590 E                      www.wandfluh.com  Illustrations are not binding  Data subject to change  3/3  Edition: 17 45  2.3-590 E
