Proportional pressure relief valve
Proportional pressure relief valve

Proportional pressure relief cartridge
◆ direct operated M18 x 1,5
◆ Q = 8 l/min ISO 7789
max
◆ p = 350 bar
max
◆ p = 315 bar
N max

DESCRIPTION APPLICATION
Direct operated proportional pressure relief valve in screw-in The electrical remote control in conjunction with process controls
cartridge construction for cavity according to ISO 7789. Good flow allows economical solutions with repeatable processes. The
capacity due to the differencial area principle, very sensitively screw-in cartridge is perfectly suitable for installation in control
adjustable. When the operating pressure adjusted by means of the blocks and is installed in sandwich- (vertical stacked systems) and
proportional solenoid is reached, the valve opens and connects the in flange plates (corresponding data sheets in this register). For
protected line with the drain to the tank. The back pressure in T (2) machining the cartridge cavity in steel and aluminum blocks, cavity
affects the pressure in P (1). For the control, Wandfluh proportional tools are available (hire or purchase). Please refer to the data

amplifiers are available (see register 1.13). sheets in register 2.13.

SYMBOL ACTUATION
Actuation Proportional solenoid, wet pin push
(T) 2 type, pressure tight
Execution PI29V (Data sheet 1.1-90)
Connection Connector socket EN 175301 – 803

(P) 1

TYPE CODE

B D P PM18 - - - #
Pressure relief valve
Direct operated

Proportional

Screw-in cartridge M18 x 1,5
Nominal pressure range p N 20 bar 20 200 bar 200
100 bar 100 315 bar 315

Nominal voltage U 12 VDC G12
N
24 VDC G24

Sealing material NBR
FKM (Viton) D1
Design index (subject to change)
2.3-520

www.wandfluh.com Illustrations are not binding Data subject to change 1/3 Edition: 19 15 2.3-520 E
