Proportional                                                                                                                 Proportional
                                                                             Proportional pressure relief valve                                                                                                   pressure reducing valves
                                                                                         pressure relief valves

       SCREW-IN CARTRIDGES INSTALLED                                                                                               Proportional pressure reducing valve
       The following screw-in cartridges are used in either the flange body or the sandwich body:                                  Flange and sandwich construction
                                                                                                                                   •  Pilot operated                                        ®
       Type        Designation                        Data sheet no.   Q max *                                                     •  Q     = 8 l/min                           NG3-Mini
       BVPPM22     pilot operated                           2.3-529   100 l/min                                                    •  p max   = 315 bar
       BNIPM22     pilot operated, inverse                  2.3-533   100 l/min                                                       max
       BVBPM22     pilot operated, explosion proof Ex d     2.3-536   100 l/min
       BVPPM22-../ME  pilot operated, with integrated electronics   2.3-537   100 l/min
       BDPPM22     direct operated                          2.3-539   25 l/min
       BDBPM22     direct operated, explosion proof Ex d    2.3-547   25 l/min                                                     DESCRIPTION                        FUNCTION                           APPLICATION
       BDPPM22-../ME  direct operated, with integrated electronics   2.3-561   25 l/min                                            Pilot operated proportional pressure reducing   By adjusting the electric current to the propor-  The valves have their applications in hydraulic
                                                                                                                                   valves NG3-Mini. Flange and sandwich con-  tional solenoid the pressure in the controlled   systems in which the pressure in a consumer
       *   Can deviate from the values on the data sheets of the screw-in cartridges.                                              struction according to Wandfluh standard with   port will be changed proportionally to the sole-  has to remain constant at the adjusted value
                                                                                                                                   4 ports. Incorporated are proportional pressure   noid current. A pressure rise in the controlled   independently of pressure fluctuations on the
                                                                                                                                   reducing cartridges size M18x1,5 according to   port above the adjusted value, caused e.g.   supply side. The facility for remote control and
                                                                                                                                   Wandfluh standard. Adjustment by Wandfluh   by an active oil consumer, will be prevented   signal processing from process control systems
       GENERAL SPECIFICATIONS                                                                                                      proportional solenoids (Standard VDE 0580).   by reliefing excessive flow to the tank line T.   enable economical solutions to problems with
       Description       Pilot operated proportional                REMARK!                                                        The flange body and the sandwich plates made   This  proportional  pressure  reducing  valves   repeatable sequences. NG3-Mini valves are
                         pressure relief valve                      Detailed performance data and additional hydraulic and         of steel are painted or zinc-nickel coated.  are adjustable very sensitivly. To control the   used  where  both,  reduced  dimensions  and
       Nominal size      NG10 according to ISO 4401-05              electric specifications may by drawn from the data sheets                                         valve proportional amplifiers are available from   weight are important.
       Constructions     Flange or sandwich                         of the corresponding installed screw-in cartridge.                                                Wandfluh (see register 1.13).
       Operations        Proportional solenoid
       Mounting          4 fixing holes for socket head cap screws
                         M6 or studs M6                             CAUTION!                                                                     10                           20
       Connections       Threaded connection plates                 The performace data especially the „pressure-flow-cha-         TYPE CODE                                            25                               20
                         Multi-flange subplates                     racteristic„ on the data sheets of the screw-in catridges             15                                            24     M  V   P     A03  -     -   10  -     #
                         Longitudinal stacking system               refere to the screw-in cartridges only. The additional press-                                       P     G1/8"                                      P        G1/8"
       Weight:           • Flange type        m = 2,34 kg           ure drop of the flange body respectivly sandwich body must     ∅ 7,5  Pressure reducing valve ∗  A    B                         ∗
       (without screw-in cartridge)  • Sandwich type P, A, B   m = 1,70 kg  be taken into consideration.                             ∅ 4,2                          T      To     30                             21  11  T  A  B  To  30
                         • Sandwich type AB   m = 1,94 kg                                                                          Pilot operated                               15                                                  15
                                                                                                                                   Proportional
                                                                                                                                      5,5
                                                                                                                                            24,5
       DIMENSIONS                                                                                                                  Flange construction    F      53  72   19              40                     63          29
                                                                                                                                            30
       Flange construction                                  Sandwich construction in A, B or AB                                    Sandwich construction   S                                                         92
                  10                          20                                          54                                       Mounting interface acc. to Wandfluh standard, NG3-Mini
                                                                                          48
            20                                                                           20,8                                      Type list / Function   flange construction    sandwich construction
                                                                                                                                          15
                                                                                                                                                          from P → A    P/A      in P          P
                                       P                                                  P
                       ∗                       G1/4"                        ∗                       ∗                                     14                                     in A          A
                                     A   B                                              A   B
                 ♦       60       T         To      60        ♦       ♦           46  T        To  26,5  60                                                                P        G1/8"
                                                                                                                                                     ∗
                                                                                                                                                                        A
                          38                   30  38  41                                            30  38                        Nominal pressure range p N red     20 bar     20  B
                                                                                                                                      ∅ 4,2               100 bar     T  100  To         30
                     6,5                                                                                                                                  200 bar       200          15  20,5
         30   40                  70      45                                              B= 1  10
                     Ø                                                                                                                                    315 bar       315
            70                       115                                               A= 110
                                                                                        AB= 132
                                                                                                                                   Nominal voltage U N    12 VDC   63   G12   29
                                                                                                                                            30
                                                                                                                                                          24 VDC      92  G24
       Sandwich construction in P                                                                                                  Design-Index (Subject to change)
                                                            ∗  The envelop dimensions of the screw-in cartridge are shown on
                                     ∗  P
                         ∗                                     their corresponding data sheets.
                                     A   B
         ♦       ♦
                                  T         To
                                                            ♦  Distance plate ADP10/... must be ordered separatly.
                                                                                                                                   TYPE LIST / FUNCTION
                                                                                                                                   Flange construction:      Sandwich construction:
                                                                                                                                                                A  P red.  T     B         A       P T      B        A        P T      B
       PARTS LIST                                           ACCESSORIES
                                                            Proportional amplifier            register  1.13
        Position   Article   Description
                                                            Distance plate ADP10/29,5 (29,5 mm)   art. no. 173.4456                  A       P T      B
        10      160.2140   O-ring ID 14,00 x 1,78 (NBR)                                                                                                         A       P T      B        A red.   P T      B         A       P T    B red.
        20      238.2406   Plug VSTI G1/4"-ED                                                                                      MVPFA03-P/A                MVPSA03 - P                MVPSA03 - A
                                                            Technical explanation see data sheet 1.0-100





       Wandfluh AG        Tel.  +41 33 672 72 72   E-mail:  sales@wandfluh.com   Illustrations not obligatory   Data sheet no.     Wandfluh AG         Tel.  +41 33 672 72 72   E-mail:  sales@wandfluh.com   Illustrations not obligatory   Data sheet no.
       Postfach           Fax  +41 33 672 72 12   Internet:  www.wandfluh.com   Data subject to change   2.3-760E 2/2              Postfach            Fax  +41 33 672 72 12   Internet:  www.wandfluh.com   Data subject to change   2.3-800E 1/2
       CH-3714 Frutigen                                                                            Edition 17 01                   CH-3714 Frutigen                                                                             Edition 21 30
