Proportional pressure relief valve
Proportional pressure relief valve Proportional-Druckregelventil

TYPE CODE DIMENSIONS
B P A03 - - - - # Flange execution Sandwich execution
Pressure relief valve B.PFA03-P BDPSA03-...
7.5
Pilot operated V
Direct operated D 4.3
MD= 2.6Nm
2.5
Proportional 5 68.8
Flange construction F
Sandwich construction S 30
25
Mounting interface according to Wandfluh standard, NG3-Mini
10 20 MD=5.5Nm MD= 1.2Nm
Type list / flange construction sandwich construction MD= 18Nm 10 66
Function in P P in P P 67 4.7
in A A
in B B
in A and B AB

Nominal pressure range p pilot operated direct operated
N
20 bar 20 20 bar 20 Sandwich execution Sandwich execution
100 bar 100 100 bar 100 B.PSA03-P BVPSA03-...
200 bar 200 200 bar 200
315 bar 315 315 bar 315 P
A B 30
Nominal voltage U 12 VDC G12
N
24 VDC G24 T To
Sealing material NBR 10 68.8
FKM (Viton) D1 48

Design index (subject to change) 80 4.7
2.3-700

MD=5.5Nm MD= 1.2Nm
10 66
HYDRAULIC SPECIFICATIONS PERFORMANCE SPECIFICATIONS Sandwich execution

Working pressure p = 350 bar Detailed performance specifications as well as further B.PSA03-A / B / AB
max Note!
Nominal pressure Pilot or direct operated hydraulic specifications can be found on the data sheet 31.9
range P = 20 bar, 100 bar, 200 bar, 315 bar of the pressure reducing cartridge installed.
N 29.5
Volume flow range Q = 0…8 l/min Attention! The performance data especially the „pressu-
Fluid Mineral oil, other fluid on request re-flowcharacteristic„ on the data sheets of the 0.25
Viscosity range 12 mm /s…320 mm /s screw-in catridges refere to the screw-in cartridges 2.4
2
2
Temperature range -25…+70 °C (NBR) only. The additional pressure drop of the flange body
fluid -20…+70 °C (FKM) respectivly sandwich body must be taken into conside- P
Contamination Class 18 / 16 / 13 ration. A B 30 4.2
efficiency T To
Filtration Required filtration grade ß 6…10 ≥ 75,
see data sheet 1.0-50 10 10 30 40
48 25
MD=18Nm
96
VALVES INSTALLED B.PSA03-A: Cartridge on A side
The following screw-in cartridges are used in either the flange body or the sandwich body. B.PSA03-B: Cartridge on B side
B.PSA03-AB: Cartridge on A and B side
Article Description Data sheet no.
BVPPM18 Proportional pressure relief cartridge pilot operated 2.3-510
BDPPM18 Proportional pressure relief cartridge direct operated 2.3-520

www.wandfluh.com Illustrations are not binding Data subject to change 2/4 Edition: 21 24 2.3-700 E www.wandfluh.com Abbildung unverbindlich Änderungen vorbehalten 3/4 Ausgabe: 21 24 2.3-700 D
